System
Processor: Intel - 3 GHz
Working memory: 1024 MB RAM
Software: installed and on SmartMedia-cards
Graphics: integrated graphics, display on TV, VGA output for optional two-monitor suite system
DVD-drive: DVD-Arabesk with Double-Layer technology, internal
SmartMedia: 4-128 MByte capacity, 3,3V

Recording system
Principle: dual-stream playback, real time effects, Direct DV
Storage: 300 GB IDE hard-disk (removable frames)
Backup drive: 300 GB IDE hard-disk (internal)
Max. capacity: currently up to 300 per hard-disk (with SMART EDIT)
Recording time: about 18 hours using a 300 GByte hard-disk

Video
TV standard: PAL-B/G 50 Hz or NTSC-M 60 Hz
Chipset: C-Cube Codec
Inputs: Front: CVBS, Y/C, i-Link DV, Rear: CVBS, Y/C, i-Link DV
Outputs: Front: i-Link, Rear: SCART (CVBS, RGB) (typ. 75 Ohm), CVBS, Y/C, i-Link DV

Audio
Inputs: Front: microphone, Stereo RCA, i-Link, Rear: Stereo-RCA, i-Link
Outputs: Front: i-Link, Rear: SCART, Stereo-RCA, i-Link

Additional external plugs
VGA (Monitor)
4 * USB
Ethernet
Trackball (USB)
Keyboard (USB)

Mechanics
Measurements WHD: approx. 315 * 245 * 335 mm
Weight: approx. 14 kg





The features shown and described might slightly differ from the release version.
